Linear Guide Rail And Block

Product Introduction

As a professional linear motion manufacturer with 12+ years of production experience, we supply standard MGN7C miniature linear guide rail assemblies, a 7mm narrow-type square miniature ball linear guide system for ultra-compact precision equipment. MGN7C is the standard short block model of MGN7 series, matched with MGR7 guide rail (rail width 7mm). The whole set consists of precision ground guide rail, MGN7C standard slide block, stainless steel ball retainer, multi-layer dustproof sealing components and side grease fitting.
Core dimension overview: Rail width 7mm; Block width 17mm, height 12mm, block length 22.5mm; Mounting screw M2 standard size Two material options for selection: GCr15 bearing steel (high load, cost-effective) / full stainless steel (anti-rust, cleanroom compatible) Precision grades: C (Commercial), H (High), P (Precision); Preload grades Z0 (light preload), Z1 (medium preload) Custom support: Any rail length cutting (100mm–4000mm), single block / block+rail combination, OEM laser engraving, customized dustproof/lubrication accessories This miniature linear guide balances tiny volume, stable rigidity and ultra-smooth linear motion, perfectly solving the space limitation problem of mini automation equipment, widely used as a replacement for imported HIWIN MGN7C guides with consistent interchangeability.
Get a Quote

Core Product Features

Ultra Compact & Lightweight Design

Narrow 7mm rail profile, ultra-small cross-section structure, greatly saving internal installation space of mini machines; low self-weight reduces equipment moving load, ideal for portable and mini precision devices.

4-Point Gothic Arch Contact, Equal Load in 4 Directions

Adopts 45° gothic arc raceway & 4-row recirculating ball structure, evenly bears radial, reverse radial, horizontal and overturning torque loads. Higher rigidity than 2-row miniature guides, stable motion under complex offset loads without jitter.

Built-In Ball Retainer, Interchangeable Structure

Integrated micro steel ball retainer prevents balls falling off when disassembling the block from rail, convenient for installation, maintenance and replacement. Same precision grade rails & blocks can be freely matched, no need to pair as original sets, greatly reduce spare parts inventory cost.

Ultra-Low Friction, Smooth & Low Noise Movement

Superfinishing grinding on rail raceway surface, friction coefficient ≤0.003; rolling friction instead of sliding friction, low driving force, high-speed stable operation, running noise ≤45dB, suitable for silent precision testing equipment.

Wide Application Fields

MGN7C miniature linear guide is tailor-made for all mini equipment requiring
precise linear movement, covering these mainstream industries:

3D Printing & Desktop CNC Equipment

Cartesian 3D printer X/Y/Z axis motion, mini engraving machine, laser marking small sliding platform, stable high-speed printing & engraving without layer deviation.

Medical Diagnostic Instruments

Biochemical analyzer sample rack slide, ultrasound probe moving module, micro surgical robot end effector, blood testing equipment, stainless steel version meets medical anti-rust clean standards.

Precision Measuring & Optical Instruments

Coordinate measuring machine (CMM) micro probe axis, laser scanner, microscope objective moving platform, optical lens adjustment slide, guarantee ultra-stable detection accuracy.

Semiconductor & Electronic Automation

Wafer inspection stages, IC chip packaging manipulator, SMT mini placement head slide, AOI optical detection equipment, PCB micro cutting machines, support micron-level component assembly.

Product Parameter

Model Aperture D L Torque(N.m) Allowable speed(min-1) Tightening torque
d1 d2
Min Max Min Max Min Max
JT16 5 8 5 8 16 23 0.5 1.0 24000 0.7
JT16C 5 8 5 8 1.0

Professional Technical Support (Factory One-Stop Service) Pre-Sales Technical Consultation

Free parameter matching: Provide load, travel, speed, environment, precision requirements, our engineers calculate dynamic/static load and recommend suitable preload & precision grade
Free dimension drawing: Send 2D/3D CAD drawings of MGN7C for your mechanical design verification
Sample support: Small trial samples available for performance testing before bulk order, fast 3–5 days sample lead time

After-Sales Technical Guidance

Detailed installation manual, lubrication & maintenance guide provided with every shipment
Online video support for installation, preload adjustment and fault troubleshooting
Engineering team online support 12 hours/day for equipment motion optimization scheme
Datasheet download: Complete catalog with load curve, tolerance table, mounting dimension chart for your technical team

Strict Quality Assurance

Full Production Inspection System

1.Raw material incoming inspection: Hardness test for GCr15/stainless steel raw steel, reject unqualified blanks
2.Semi-finished grinding inspection: 100% raceway surface roughness & dimensional tolerance detection
3.Finished product full testing: Straightness, parallelism, preload uniformity, sliding smoothness test for every set of guides
4.Random load fatigue test: Sampling long-cycle reciprocating test to verify service life under rated load

Factory Warranty Policy

12-month factory warranty for all MGN7C linear guides under normal installation & operation (exclude man-made damage, overload, corrosion from chemical liquid)
Within warranty period, free replacement for quality defects such as precision deviation, abnormal block jamming
Long-term spare parts supply: We keep full stock of MGN7C blocks and rails for after-sales replacement within 24 hours delivery

Authorized Quality Certifications

ISO9001 quality management system certified; raw material SGS material test report; export product factory inspection certificate available on request.

Proven with Industry Leaders

Specification Guide

Want Some
More Inspiration?

Take a look at our latest look book below.
Download

Got a Q? We got an A for that.

Have Some Questions
About Our Linear guideways.

What is the difference between ball and roller linear sliders, how to choose?

Ball sliders suit light load, high speed & low noise applications like automation and 3D printers. Roller sliders feature high rigidity, heavy load capacity and impact resistance for CNC machines and woodworking equipment.

How to select preload grade Z0/Z1/Z3 for sliders?

Z0 zero preload: low resistance for simple conveyors; Z1 light preload eliminates clearance for CNC & packaging machines; Z3 heavy preload for ultra-precision 5-axis machines and inspection equipment.

What causes abnormal noise of linear guides & sliders? How to fix it?

Insufficient lubrication, dust contamination, unparallel mounting base or damaged steel balls. Install self-lubrication and double dust-proof accessories, re-calibrate mounting surface or replace defective sliders.

Which sliders fit dusty woodworking & humid food machinery?

Sliders with double dust seals and scrapers, stainless steel rails or anti-rust coating are recommended. E2 self-lubrication units prevent chips and powder entering circulation circuits.

Can linear guide rails be customized to non-standard lengths? What’s the maximum single length?

Custom cut-to-length available. Max single rail length is 6m; longer stroke adopts spliced rails with professional joint processing.

Installation difference between flange, high-profile and low-profile sliders?

Flange sliders with through holes have low mounting height and balanced load; high-profile sliders offer higher load capacity; low-profile sliders fit narrow internal equipment space.

Application for C/H/P/SP/UP accuracy grade linear guides?

C/H: packaging & general woodworking machines; P: CNC milling & standard automation; SP/UP: 5-axis machine tools, precision testers and SLA 3D

Slider jerks and moves unsmoothly, how to troubleshoot?

Check flatness of mounting base, evenly tighten bolts, clean foreign particles inside circulation paths, replenish grease and correct rail parallelism.

Can you supply integrated linear modules with matching ball screws, guides and sliders?

Yes. We provide one-stop customized linear motion modules, matched with proper ball screws and guides according to load, stroke and accuracy requirements, delivered as finished slides ready for assembly.

What is the lead time for samples and mass orders?

Standard samples: 1–3 days; non-standard modified sliders with special protection: 3–7 days; mass production orders: 7–15 days, flexible scheduling for bulk orders.
